功能介绍界面截图核心源码功能介绍
图形化界面，使用tkinter实现
可以输入单个IP地址或CIDR格式的网段
支持扫描Oracle、SQL Server、MySQL、PostgreSQL和SQLite五种数据库
实时显示扫描结果，并按数据库类型分类显示
显示每种数据库类型的发现数量
可以随时停止扫描
多线程实现，不会卡住界面
不会弹出命令行窗口
界面截图
核心源码
import tkinter as tkfrom tkinter import ttk, messagebox, filedialogimport threadingimport ipaddressimport socketimport queueimport timeimport xml.etree.ElementTree as ETfrom datetime import datetimeimport osimport matplotlib.pyplot as pltfrom matplotlib.figure import Figurefrom matplotlib.backends.backend_tkagg import FigureCanvasTkAggimport matplotlibmatplotlib.use('TkAgg') class DatabaseScanner: def __init__(self): self.root = tk.Tk() self.root.title("数据库服务器扫描工具") # 获取屏幕尺寸 screen_width = self.root.winfo_screenwidth() screen_height = self.root.winfo_screenheight() # 设置窗口初始大小为屏幕的80%宽度和90%高度 window_width = int(screen_width * 0.8) window_height = int(screen_height * 0.9) # 增加高度比例 # 计算窗口位置使其居中 x = (screen_width - window_width) // 2 y = (screen_height - window_height) // 2 # 设置窗口大小和位置 self.root.geometry(f"{window_width}x{window_height}+{x}+{y}") # 设置窗口最小尺寸 self.root.minsize(800, 800) # 增加最小高度 # 设置主题色 self.colors = { 'bg': '#f0f0f0', 'frame_bg': '#ffffff', 'button': '#2196f3', 'button_hover': '#1976d2', 'success': '#4caf50', 'warning': '#ff9800', 'error': '#f44336' } # 设置样式 self.style = ttk.Style() self.style.configure('Main.TLabelframe', background=self.colors['frame_bg']) self.style.configure('Main.TLabelframe.Label', background=self.colors['frame_bg'], font=('微软雅黑', 10, 'bold')) self.style.configure('Scan.TButton', background=self.colors['button'], font=('微软雅黑', 9)) self.style.configure('Report.TButton', background=self.colors['success'], font=('微软雅黑', 9)) # 创建数据存储变量 self.scan_running = False self.result_queue = queue.Queue() self.db_results = { 'Oracle': [], 'SQL Server': [], 'MySQL': [], 'PostgreSQL': [], 'SQLite': [] } self.root.configure(bg=self.colors['bg']) self.setup_ui() def setup_ui(self): # 创建主框架，使用grid布局 main_frame = ttk.Frame(self.root) main_frame.grid(row=0, column=0, sticky="nsew") # 配置root和main_frame的grid权重 self.root.grid_rowconfigure(0, weight=1) self.root.grid_columnconfigure(0, weight=1) # 调整各区域的相对大小比例 main_frame.grid_rowconfigure(0, weight=0) # 扫描设置固定高度 main_frame.grid_rowconfigure(1, weight=1) # 进度日志区域 main_frame.grid_rowconfigure(2, weight=3) # 增加图表区域的比例 main_frame.grid_rowconfigure(3, weight=4) # 增加结果区域的比例 main_frame.grid_columnconfigure(0, weight=1) # 输入框框架 input_frame = ttk.LabelFrame(main_frame, text="扫描设置", padding=10, style='Main.TLabelframe') input_frame.grid(row=0, column=0, sticky="ew", padx=10, pady=5) ttk.Label(input_frame, text="IP地址/网段:", background=self.colors['frame_bg'], font=('微软雅黑', 9)).grid(row=0, column=0, padx=5) self.ip_entry = ttk.Entry(input_frame, width=40, font=('微软雅黑', 9)) self.ip_entry.grid(row=0, column=1, padx=5) self.ip_entry.insert(0, "192.168.1.0/24") button_frame = ttk.Frame(input_frame, style='Main.TLabelframe') button_frame.grid(row=0, column=2, padx=5) self.scan_button = ttk.Button(button_frame, text="开始扫描", command=self.start_scan, style='Scan.TButton') self.scan_button.pack(side=tk.LEFT, padx=2) self.report_button = ttk.Button(button_frame, text="生成报告", command=self.generate_report, style='Report.TButton') self.report_button.pack(side=tk.LEFT, padx=2) # 配置input_frame的列权重 input_frame.columnconfigure(1, weight=1) # 进度日志框架 log_frame = ttk.LabelFrame(main_frame, text="扫描进度", padding=10, style='Main.TLabelframe') log_frame.grid(row=1, column=0, sticky="ew", padx=10, pady=5) self.progress_var = tk.StringVar(value="等待开始扫描...") self.progress_label = ttk.Label(log_frame, textvariable=self.progress_var, background=self.colors['frame_bg'], font=('微软雅黑', 9)) self.progress_label.pack(fill=tk.X) self.log_text = tk.Text(log_frame, height=4, font=('微软雅黑', 9)) self.log_text.pack(fill=tk.BOTH, expand=True) self.log_text.configure(bg='#fafafa', fg='#333333') log_scrollbar = ttk.Scrollbar(log_frame, command=self.log_text.yview) log_scrollbar.pack(side=tk.RIGHT, fill=tk.Y) self.log_text.config(yscrollcommand=log_scrollbar.set) # 添加统计图表框架 chart_frame = ttk.LabelFrame(main_frame, text="数据库统计", padding=10, style='Main.TLabelframe') chart_frame.grid(row=2, column=0, sticky="nsew", padx=10, pady=5) # 创建图表 self.figure = Figure(dpi=100) # 移除固定figsize self.figure.patch.set_facecolor(self.colors['frame_bg']) self.chart_ax = self.figure.add_subplot(111) self.canvas = FigureCanvasTkAgg(self.figure, master=chart_frame) self.canvas.get_tk_widget().pack(fill=tk.BOTH, expand=True) # 初始化图表 self.update_chart() # 结果显示框架 result_frame = ttk.LabelFrame(main_frame, text="扫描结果", padding=10, style='Main.TLabelframe') result_frame.grid(row=3, column=0, sticky="nsew", padx=10, pady=5) # 创建数据库类型标签页 self.notebook = ttk.Notebook(result_frame) self.notebook.pack(fill=tk.BOTH, expand=True) # 为不同数据库类型设置不同的颜色 db_colors = { 'Oracle': '#f44336', 'SQL Server': '#2196f3', 'MySQL': '#4caf50', 'PostgreSQL': '#ff9800', 'SQLite': '#9c27b0' } self.db_text_widgets = {} for db_type in self.db_results.keys(): frame = ttk.Frame(self.notebook, style='Main.TLabelframe') self.notebook.add(frame, text=f"{db_type} (0)") text_widget = tk.Text(frame, height=8, font=('微软雅黑', 9)) text_widget.pack(fill=tk.BOTH, expand=True) text_widget.configure(bg='#fafafa', fg=db_colors[db_type]) scrollbar = ttk.Scrollbar(frame, command=text_widget.yview) scrollbar.pack(side=tk.RIGHT, fill=tk.Y) text_widget.config(yscrollcommand=scrollbar.set) self.db_text_widgets[db_type] = text_widget # 绑定窗口大小改变事件 self.root.bind('<Configure>', self.on_window_resize) def on_window_resize(self, event): """当窗口大小改变时调整图表大小""" if hasattr(self, 'canvas'): # 延迟更新以避免频繁刷新 self.root.after_cancel(self._resize_job) if hasattr(self, '_resize_job') else None self._resize_job = self.root.after(100, self.update_chart) def validate_ip_input(self, ip_input): try: if '/' in ip_input: # CIDR格式 ipaddress.ip_network(ip_input, strict=False) else: # 单个IP地址 ipaddress.ip_address(ip_input) return True except ValueError: return False def start_scan(self): if self.scan_running: self.scan_running = False self.scan_button.config(text="开始扫描") return ip_input = self.ip_entry.get().strip() if not self.validate_ip_input(ip_input): messagebox.showerror("错误", "请输入有效的IP地址或网段") return # 清空之前的结果 for db_type in self.db_results: self.db_results[db_type] = [] self.db_text_widgets[db_type].delete(1.0, tk.END) self.notebook.tab(list(self.db_results.keys()).index(db_type), text=f"{db_type} (0)") # 重置图表 self.update_chart() self.scan_running = True self.scan_button.config(text="停止扫描") # 启动扫描线程 scan_thread = threading.Thread(target=self.scan_network, args=(ip_input,)) scan_thread.daemon = True scan_thread.start() # 启动更新UI的线程 self.root.after(100, self.update_results) def scan_network(self, ip_input): try: if '/' in ip_input: # 网段 network = ipaddress.ip_network(ip_input, strict=False) ip_list = list(network.hosts()) else: # 单个IP ip_list = [ipaddress.ip_address(ip_input)] total_ips = len(ip_list) for index, ip in enumerate(ip_list, 1): if not self.scan_running: break ip_str = str(ip) progress = f"正在扫描: {ip_str} ({index}/{total_ips})" self.result_queue.put(("progress", progress)) self.result_queue.put(("log", f"正在扫描 {ip_str}...\n")) # 检查各种数据库端口 self.check_database_ports(ip_str) except Exception as e: self.result_queue.put(("error", f"扫描出错: {str(e)}")) finally: self.scan_running = False self.result_queue.put(("progress", "扫描完成")) self.result_queue.put(("log", "扫描已完成\n")) self.root.after(0, lambda: self.scan_button.config(text="开始扫描")) def check_database_ports(self, ip): # 定义数据库默认端口 db_ports = { 'Oracle': [1521], 'SQL Server': [1433], 'MySQL': [3306], 'PostgreSQL': [5432], 'SQLite': [] # SQLite是文件型数据库，没有网络端口 } for db_type, ports in db_ports.items(): for port in ports: try: sock = socket.socket(socket.AF_INET, socket.SOCK_STREAM) sock.settimeout(1) result = sock.connect_ex((ip, port)) if result == 0: self.result_queue.put(("found", db_type, ip, port)) sock.close() except: continue def update_chart(self): """更新统计图表""" self.chart_ax.clear() # 获取图表区域的大小 chart_width = self.canvas.get_tk_widget().winfo_width() chart_height = self.canvas.get_tk_widget().winfo_height() # 调整图表的纵横比 aspect_ratio = chart_height / chart_width # 根据窗口大小调整图表尺寸，保持合适的纵横比 self.figure.set_size_inches(chart_width/100, (chart_width * aspect_ratio)/100) # 准备数据 db_types = list(self.db_results.keys()) counts = [len(ips) for ips in self.db_results.values()] colors = ['#f44336', '#2196f3', '#4caf50', '#ff9800', '#9c27b0'] # 创建柱状图 bars = self.chart_ax.bar(db_types, counts, color=colors) # 设置图表样式 plt.rcParams['font.sans-serif'] = ['Microsoft YaHei'] # 使用微软雅黑字体 plt.rcParams['axes.unicode_minus'] = False self.chart_ax.set_ylabel('数量', fontsize=10) self.chart_ax.set_title('数据库服务器统计', fontsize=12, pad=10) # 设置Y轴范围和刻度 max_count = max(counts) if counts else 0 self.chart_ax.set_ylim(0, max_count + 1 if max_count > 0 else 1) self.chart_ax.yaxis.set_ticks(range(0, int(max_count + 2))) # 设置背景颜色和网格 self.figure.patch.set_facecolor(self.colors['frame_bg']) self.chart_ax.set_facecolor('#f8f9fa') self.chart_ax.grid(True, axis='y', linestyle='--', alpha=0.3) # 美化X轴标签 self.chart_ax.set_xticklabels(db_types, rotation=0, fontsize=9) # 在柱子上显示具体数值 for bar in bars: height = bar.get_height() self.chart_ax.text(bar.get_x() + bar.get_width()/2., height, f'{int(height)}', ha='center', va='bottom', fontsize=10, fontweight='bold') # 调整布局，确保所有元素都能显示 self.figure.tight_layout() # 刷新画布 self.canvas.draw() def update_results(self): while not self.result_queue.empty(): message = self.result_queue.get() if message[0] == "found": _, db_type, ip, port = message if ip not in self.db_results[db_type]: self.db_results[db_type].append(ip) self.db_text_widgets[db_type].insert(tk.END, f"{ip}:{port}\n") self.notebook.tab(list(self.db_results.keys()).index(db_type), text=f"{db_type} ({len(self.db_results[db_type])})") self.result_queue.put(("log", f"发现 {db_type} 服务器: {ip}:{port}\n")) # 更新统计图表 self.update_chart() elif message[0] == "error": messagebox.showerror("错误", message[1]) elif message[0] == "progress": self.progress_var.set(message[1]) elif message[0] == "log": self.log_text.insert(tk.END, message[1]) self.log_text.see(tk.END) if self.scan_running: self.root.after(100, self.update_results) def generate_report(self): if not any(self.db_results.values()): messagebox.showwarning("警告", "没有扫描结果可供生成报告！") return try: # 创建XML报告 root = ET.Element("ScanReport") ET.SubElement(root, "ScanTime").text = datetime.now().strftime("%Y-%m-%d %H:%M:%S") ET.SubElement(root, "ScanTarget").text = self.ip_entry.get() databases = ET.SubElement(root, "Databases") for db_type, ips in self.db_results.items(): db_elem = ET.SubElement(databases, "Database") ET.SubElement(db_elem, "Type").text = db_type ET.SubElement(db_elem, "Count").text = str(len(ips)) servers = ET.SubElement(db_elem, "Servers") for ip in ips: server = ET.SubElement(servers, "Server") server.text = ip # 保存文件对话框 file_path = filedialog.asksaveasfilename( defaultextension=".xml", filetypes=[("XML files", "*.xml")], initialfile=f"scan_report_{datetime.now().strftime('%Y%m%d_%H%M%S')}.xml" ) if file_path: tree = ET.ElementTree(root) tree.write(file_path, encoding="utf-8", xml_declaration=True) self.result_queue.put(("log", f"扫描报告已保存至: {file_path}\n")) messagebox.showinfo("成功", "扫描报告已生成！") except Exception as e: messagebox.showerror("错误", f"生成报告时出错: {str(e)}") def run(self): self.root.mainloop() if __name__ == "__main__": scanner = DatabaseScanner() scanner.run()
